Electrostatic Precipitators
NWL, part of AMSC, is a leading manufacturer of Electrostatic Precipitator (ESP) products, offering a range of power supplies ESP performance and efficiency.
Overview
Discover the future of air pollution control with NWL, brought to you by AMSC. NWL is a leading manufacturer of Electrostatic Precipitator (ESP) products, offering a range of power supplies and ancillaries that enhance ESP performance and efficiency. NWL’s flagship product, PowerPlus™, revolutionizes ESP power with high voltage/high frequency switch mode technology. PowerPlus™ uses Insulated Gate Bipolar Transistors (IGBTs). Our IGBTs allow for an enhanced power supply that operates at a much higher frequency, easily managing large currents and high voltages when compared to conventional single-phase units.
NWL’s compact ESPs integrate a current limiting reactor (CLR), Transformer/Rectifier (T/R) set, and the controller functions into one powerful package. Customers have reliably trusted our T/R sets for over 50 years. When used with our CLRs, you can maintain safe and efficient ESP operation with precise current flow. Sized to perform two functions, our CLRs protect circuit components and shape the AC sine wave. NWL CLRs can come as an open frame that easily fits into a desired space, with a NEMA rated enclosure, or as part of a T/R set. Included in the, PowerPlus™, we offer advanced control options for ESPs including the Graphic Rapper Controller, the Graphic Voltage Controller, and the Precipitator Control and Management System. PowerPlus™ models come in three different kV rating options, so you can rest assured that we have the rating you need. By adding PowerPlus™ to your applications, you achieve optimal fine particle removal, for a cleaner and compliant operations.
NWL ESPs can also come with innovate additions like our PowerCube™, a modern replacement for outdated silicon-controlled rectifier (SCR) assemblies with a more reliable solid-state thyristor. Our PowerCube™ enhances safety by ensuring the heat sinks are not energized and features a more compact footprint, easily retrofitted in place of most SCR puck and heat sink locations.
Many industries can unlock the unmatched benefits of NWL’s advanced ESPs. Power plants, cement factories, steel mills, and other industrial facilities can achieve superior air quality control, maintain compliance with strict environmental regulations, and promote a healthier environment. NWL’s advanced ESP technology enhances operational efficiency and significantly reduces maintenance costs, for a robust return on investment. By adding NWL’s smart solutions, industries can elevate their sustainability practices, boost their green credentials, and contribute to a brighter, pollution-free future. With NWL’s industry-leading technology, you can trust in us for better and more reliable air pollution control.
Features
NWL’s Electrostatic Precipitator (ESP) products will enhance your applications for a cleaner and better future. Our ESP products and features include:
- PowerPlus™ which combines the controller, the current limiting element, and the T/R set functions into one compact high voltage power supply for the ESP.
Specifics include:
- Three models by kV rating
- Increased collection efficiency
- Decreased kVA for the same amount of power applied to the field
- Faster spark response with less wasted spark current
- Significantly higher power factor
- Lower initial installation cost
- Reduced space requirement with integrated design
- Can facilitate buss and guard or cable for HV connection
- Controller
- Graphic Rapper Controller
- Ramped Intensity Pulse Rapping (RIP/RAP):
- Opacity Spike Detection:
- Anti-Coincidence Grouping:
- Power Off/Reduced Power Rapping (POR/RPR):
- And many more!
- Graphic Voltage Controller
- DSP for fast spark and arc responses and control
- Back corona detection and control
- Redundant communication options
- Easy retrofitting
- Works with all manufacturers transformer rectifiers controlled by silicon controlled rectifiers.
- And many more!
- Precipitator Control and Management System
- Energy Management
- Switchmode and T/R
- Rapper Control
- Dual Mode Hopper Management
- Interconnectivity
- Icon driven displays
- An intuitive menu
- Remote Access
- Current Limiting Reactor
- Limits spark current to protect other components in the circuit.
- Shapes the AC sine wave.
- Customization Options:
- Available as an open frame to fit specific spaces.
- Can come with a NEMA rated enclosure.
- Can come as part of a T/R set.
- Material Options:
- Built using either aluminum or copper windings.
- Design Flexibility
- NWL can design and manufacture reactors based on customer-supplied transformer ratings and either inductance or percentage of impedance.
- Available with fixed or tapped values.
- Transformer/Rectifier set
- Affordable, robust, low life-cycle-cost solution
- Available as new and replacement T/R set or as as repair and refurbishment services
- Many current and voltage options
- Many Switching Options
- Design and Construction
- Designed for safe and quick installation, operation, and maintenance
- Electrical and mechanical parameters meet all requirements specified for your ESP.
- And Many More!
- PowerCube™
- Complete module, for a plug-and-play design
- Built in snubber circuit
- Available in three current ratings: 120, 250, and 450 amps
- Options include fuse and/or trigger board
Applications
NWL’s Electrostatic Precipitator (ESP) products unlock cleaner air and superior efficiency for many industries. Our ESPs applications include but are not limited to:
- Air Quality Transformation: Our ESP products are your ultimate solution for air pollution control, ensuring your operations meet and exceed environmental regulations while contributing to a healthier planet.
- Boosting Power Plant Performance: For enhanced and efficient power plants. Can capture fly ash in coal plants, and other harmful particulates, for reduced emissions and better air quality.
- Optimizing Cement Production: For compliant and dust-free cement production for optimal emission control and a cleaner working environment.
- Elevating Metal Processing: Capture fine particles and fumes in your steel and metal processing operations, ensuring a safer and cleaner workspace.
- Enhancing Pulp and Paper Production: Our ESPs are perfect for controlling emissions from recovery boilers and lime kilns, promoting cleaner and more sustainable production processes.
- Improving Chemical Plant Efficiency: Remove particulate pollutants from process gases in chemical and petrochemical industries, boosting overall efficiency and environmental performance.
- NWL ESPs enhance the operations of many industrial applications regardless of the environment. ESPs are:
- Suitable for locations up to 3,300 feet (1,000 meters) above sea level.
- Perform well in ambient temperatures up to 40°C (104°F), with options for up to 50°C (122°F).
- Easily installed outdoors, exposed to dust, salt, and extreme weather conditions.
- Operate in temperatures from -40°F to +104°F and 10% to 100% relative humidity.
- fluid immersed, type OA, suitable for outdoor installation, exposed to elements in various climates and elevation.
Benefits
Thanks to NWL’s advanced technology, AMSC is proud to provide industry-leading Electrostatic Precipitator (ESP) products. Our ESPs will transform your industrial operations by capturing particulate matter and reducing emissions. Whether you are in power generation, cement production, metal processing, pulp and paper, or the chemical industry, NWL’s ESPs ensure compliance with environmental regulations, improve air quality, and boost overall operational efficiency. Choose NWL for a sustainable future and a commitment to excellence in air pollution control. Let us help you achieve cleaner, greener, and more efficient operations today!
